Rockwell Automation Publication 750-RM003A-EN-P - April 2018 37
Selection Considerations Chapter 1
Mechanical Vibration Non-operational; not applicable
Operating;
• 1 mm (0.039 in.) displacement,
1G peak, EN50178/EN60068-2-6
Packed for shipment;
• Meets ASTM International standards
Operating;
• 1 mm (0.040 in.) displacement,
1G peak
Sound At 1 m (3.28 ft):
• frame 10, 71 dB
• frame 13, 80 dB
At 2 m (6.6 ft), IP21/IP54:
• frame 8, 77/76 dBA
• frame 9, 80/79 dBA
• frame 10, 84/83 dBA
• frame 11, 83/82 dBA
• frame 12, 84/83 dBA
Table 12 - Certifications
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
UL • UL508C (c-UL-us). UL Listing only
applicable up to 600V AC
Designed to meet;
• NFPA 70 – US NEC
• NFPA 79 – Electrical Standard for
Industrial Machinery 2002 Edition
• NEMA ICS 7.0 – Safety standards
for Construction and Guide for
Selection, Installation and
Operation of Adjustable Speed
Drive Systems
UL61800-5-1 (c-UL-us) only applicable up
to 600V AC
CAN/CSA CSA 22.2 No. 14-05 CSA 22.2 No. 274, Adjustable Speed Drives
CE Marked for following European
Directives;
• EMC Directive (2004/108/EC) EN
61800-3 Adjustable speed
electrical power drive systems –
Part 3: EMC requirements and
specific test methods.
Low Voltage Directive (2006/95/EC)
EN 61800-5-1 Adjustable speed
electrical power drive systems-Part
5-1: Safety requirements – electrical,
thermal and energy.
In conformity with the following European
Directives:
• EMC Directive (2014/30/EU)
• Low Voltage Directive (2014/35/EU)
• RoHS Directive (2011/65/EU)
Standards applied:
• EN 61800-3
• EN 61800-5-1
(o) Additional EMI filter available, choose
catalog code (-J) for EMC filter selection.
IEC — Atmospheric Protection:
• Conformity with IEC 60721-3-3, 3C2
and 3S2, for components manufactured
by Rockwell Automation.
• IP54, UL Type 12 Cabinet is required to
meet the 3S2 requirement
ISA — Atmospheric Protection;
• Conformity Standard 71.04, for
components manufactured by Rockwell
Automation.
Class SA, SB, and SC, Severity X
environmental concentrations (airborne
particulates) with Class SD particles at
Severity 2.
Table 11 - Environmental Features (Continued)
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
