38 Rockwell Automation Publication 750-RM003A-EN-P - April 2018
Chapter 1 Selection Considerations
Functional Safety — Not applicable to PowerFlex 755TM Bus
Supplies.
PowerFlex 755TL/TR drives and PowerFlex
755TM common bus inverters; TÜV and
Rheinland - Certification applies to
20-750-S, 20-750-S1, and 20-750-S3
safety options when they are installed in
the drive and are configured according to
the appropriate safety manual.
RCM, C-Tick — Australian Communications and Media
Authority
In conformity with the following:
• Radio communications Act: 1992
• Radio communications Standard: 2008
• Radio communications Labeling Notice:
2008
Standards applied:
• EN 61800-3:2012
China RoHS2 — Compliant with China Restriction of
Hazardous Substances Directive.
KCC — Korean KC registration
ODVA — (option modules may be
compliant)
EtherNet/IP
IEEE 519 (s) (s)
REACH — Regulation (EC) No. 1907/2006 concerning
the Registration, Evaluation,
Authorization, and Restriction of
Chemicals (REACH)
Packaging Directive — In conformity with the Packaging Directive
(94/62/EC and amendments 2004/12/EC
and 2005/20/EC)
Table 13 - Protection Features
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
AC Input Overvoltage Trip — (see DC Bus Overvoltage Trip) 400/480V Class; 542V AC
600/690V Class; 780V AC
AC Input Under voltage Trip
Nominal value, adjustable
and configurable action
— (see DC Bus Under voltage
Shutdown/Fault)
400V Class; 348V AC
480V Class; 418V AC
600V Class; 522V AC
690V Class; 600V AC
DC Bus Overvoltage Trip 400/480V Class; 911V DC
600/690V Class; 1200V DC
400/480V Class; 815V DC
600/690V Class; 1172V DC
DC Bus Under voltage
Shutdown/Fault
Nominal value, adjustable
and configurable action
400/480V Class; 333V DC
600/690V Class; 461V DC
400V Class; 453V DC
480V Class; 543V DC
600V Class; 678V DC
690V Class; 781V DC
Heat Sink Temperature Fault (s) (s) over and under temperature
Ground Fault (s) (s)
Table 12 - Certifications (Continued)
Description PowerFlex 700AFE Bus Supply PowerFlex 755TM Bus Supply
Cat No. 20Y… Cat. No. 20J…
