84 Rockwell Automation Publication 750-QS001A-EN-P - March 2015
Reference Section
5. Use the or key to select Device Version.
6. Press the (Enter) key to display device version information.
7. Record the information.
Power Jumper Configuration Information
Product Series Product Revision Product Serial Number Main Control Board Firmware Revision
Power Jumper Configuration
Jumper PE-A - MOV / Input Filter Caps
❑ Connected ❑ Disconnected
Jumper PE-B - DC Bus Common Mode Caps
❑ Connected ❑ Disconnected
ESC
DIAGNOSTIC
Alarms
Diagnostic Items
Reset Device
Device Version
Stopped
0.000 Hz
AUTO
F
Stopped
0.000 Hz
AUTO
ESC
F
PowerFlex 753
Product Rev 9.001
Product Ser Num 00000000
Product Series A
–Main Control Board
FW Revision 9.001
TOP END PGUP PGDN
To Next Page
