Before you begin
Please review the following information before starting this lab.
About this lab
This session provides you with an opportunity to explore the Flying Start features of the PowerFlex 755 AC Drive. In this session
you will:
 Demonstrate a scenario in which Flying Start is not used
 Explore Flying Start Enhanced mode
 Explore Flying Start Sweep mode
This lab takes approximately 40 minutes to complete.
Lab Objective
At the end of this lab you will be able to:
1. Configure the drive for Flying Start – Enhanced
2. Configure the drive for Flying Start – Sweep
Tools & Prerequisites
Software programs required
• Connected Components Workbench v9.01
• RSLinx Classic v3.80.00
Hardware devices required
• PowerFlex 755 DHQ Demo Box (PN-39023)
o PowerFlex 755 AC Drive (20G11-N-B-DM1AA6K32V8) – v12.001
• Ethernet patch cables
• Motor with flywheel attached

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
