Allen-Bradley PowerFlex 755TL Installation Instructions

Rockwell Automation Publication 750-IN100B-EN-P - July 2017 47
Prepare for Installation Chapter 3
Frame 9 Bus Supplies Top, Front, Bottom, and Side Views - Dimensions are mm (in.)
See page 51 for optional entry wire bay dimensions.
0 (0)
535 (2.1)
451
(17.8)
45
(1.8)
200
(7.9)
600
(23.6)
1495
(58.9)
66
(2.6)
301
(11.9)
128
(5.0)
90
(3.5)
512
(20.2)
225
(8.9)
400 (15.7)
1135 (44.7)
1406
(55.4)
800
(31.5)
36
(1.4)
535
(21.1)
IP21, UL Type 1
2132
(83.9)
IP54, UL Type 12
2291
(90.2)
IP21, UL Type 1
676
(26.6)
IP54, UL Type 12
721
(28.4)
Input Power Cables - Top Entry
Signal Cables - Top Entry
Dimensions same as bottom.
Signal Cables - Bottom Entry
Mounting Holes
Input Power Cables - Bottom Entry
Power BayInput Bay
