Allen-Bradley PV550 User Manual

Publication 2711-UM014B-EN-P
Specifications A-15
Character Sizes PV1400 (Pixel size = 0.32 x 0.32 mm)
Communications
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
8 x 20 99 29 2.5 x 6.4
16 x 24 49 24 5.1 x 7.6
24 x 32 33 18 7.6 x 10.2
32 x 40 24 14 10.2 x 12.7
32 x 64 24 9 10.2 x 20.4
DH-485 Network
Baud Rate
Distance Maximum
1200, 2400, 9600, 19.2K
1219 meters (4,000 feet)
DH+ Network
Baud Rate
Distance Maximum
57.6K, 115.2K, 230.4K
3048 meters (10,000 feet)
RS-232 or DH-485 Point-to-Point
Baud Rates
Distance Maximum
1200, 2400, 9600, 19.2K
6.1 meters (20 feet)
Remote I/O
Baud Rates 57.6K, 2,800 meters (10,000 feet)
115.2K, 1,400 meters (5,000 feet)
DeviceNet
Baud Rates 125K, 250K, 500K
ControlNet Network
Baud Rate
Distance Maximum
5M
1,000 meters (3,280 feet)
EtherNet/IP Network
Distance Maximum
100 meters (328 feet)
DF1/Full Duplex Communications
Baud Rate
Distance Maximum
1200, 2400, 4800, 9600, 19.2K
15.24 meters (50 feet)
RS-232 Printer Port
Baud Rates
Parity
Data Bits
Stop Bits
Handshaking
1200, 2400, 9600, 19.2K
None, Even, Odd
7 or 8
1 or 2
None, Software (XON, XOFF), Hardware
