1 Publication 2711-UM014B-EN-P
Chapter
7
Installing the PV300 Terminal
Chapter Objectives
This chapter shows how to install the PanelView 300 terminal and
covers:
• hazardous locations
• enclosures
• required tools
• mounting dimensions
• clearances
• cutout dimensions
• installing the PV300 terminal in a panel
Hazardous Locations
See the nameplate label on terminal for hazardous location
certifications.
The PV300 terminals have an operating temperature code of T4
(maximum operating temperature of 135
° C or 275° F). Do not install
these terminals in environments where atmospheric gases have
ignition temperatures less than 135° C (275° F).
DANGER
!
Explosion Hazard
• Substitution of components may impair suitability
for Class I, Division 2.
• Do not disconnect equipment unless power has
been switched off and area is known to be
non-hazardous.
• Do not connect or disconnect components unless
power has been switched off.
• All wiring must comply with N.E.C. article
501-4(b).
