Publication 2711-UM014B-EN-P
Terminal Overview 1-29
# Feature Description
1 Function Keys (F1 - F21) Use the function keys on keypad terminals to initiate
functions on the terminal display. These keys may have
custom legends.
2Cursor Keys Use the cursor keys to move the cursor in displayed lists, to
select a numeric entry object, or to enter configuration
mode.
3 Numeric Entry Keys 0-9 Enters numeric values.
. Enters a decimal point.
- Enters a negative value.
← Clears entered digits or cancels the scratchpad.
↵ Stores an entered value.
4 Keypad Terminal Display On keypad terminals, initiate the function of a displayed
object, such as an ON or OFF push button, by pressing a
function key (F1 - F21).
5 Touch Screen
Terminal Display
On touch screen terminals, initiate the function of a
displayed object, such as an ON or OFF push button, by
touching the screen object. Each interactive screen object
occupies one or more of 384 cells.
6 Touch Cells
(Touch Screen terminal)
The 384 touch cells (24 columns x 16 rows) let you initiate
functions by touching the screen. Interactive screen objects
are aligned with touch cells when the application is created.
