2-10 Applying Power and Resetting Terminal
Press this function key on:
To set this RIO
Parameter:
Description Options
550/600 900/1000/1400
↵ F1 Rack # Rack address of terminal on RIO network.
On PV550/600: Press ↵ to open the
scratchpad. Enter the rack address and
press ↵ again.
On PV900/PV1000/PV1400: Press F1 to
set the rack #, then use the up and down
arrow keys to select an address.
0 to 76
F1 F2 Rack Size Rack size of terminal. Each key press
displays a different size. The terminal
occupies a single rack.
1/4, 1/2, 3/4, Full
F2 F3 Starting Module Group Starting module group number of the
terminal in the assigned rack. Each key
press displays a different module group.
0,1 2,3 4,5 6,7
F3 F4 Pass-Through Enabled Enables or Disables Pass-Through, which
lets you transfer applications between a
computer on a DH+ link and a terminal on
a Remote I/O link. A PLC-5 controller
passes data between the networks.
Yes or No
F4 F5 Last Chassis Specifies whether the terminal occupies
the last module group in the assigned
rack (applies only to PLC2 controllers).
Yes or No
F5 Block Transfer Timeout Timeout value for block transfers. Each
key press toggles a value.
0 to 60 seconds
(0 is the default)
F6 F6 Baud Rate Baud rate at which the terminal will
communicate on the RIO network.
BaudMax. Cable Length
57.6K 10,000 ft
115.2K 5,000 ft
230.4K 2,500ft
