Messages, Codes and Self-Test Numbers B-13
EtherNet/IP Codes
These messages appear on the terminal screen as DC Error=xx. If you
get an alert number that is not listed here, contact technical support.
Error Number Terminal
Messages
Type Meaning Recommended Action
xx,xx,xx
Number depends
on hardware fault
detected.
Communication
Interface Fault
Critical Fault A hardware problem was detected during
power-up. If you ignore message and
display the EtherNet/IP Communications
Screen, the Comm Status displays
“Comms hardware fault:” without an
error number. The FW revision, serial
number and EtherNet/IP address fields
are displayed.
Contact technical support to have unit
repaired.
770 Buffer overflow Comm Status Internal error occurred. Contact technical support.
771 Buffer underflow Comm Status Internal error occurred. Contact technical support.
1799 Heap partition
empty
Comm Status Internal error occurred. Contact technical support.
16387 Comms not started
yet . . .
Comm Status The PanelView has not connected to the
network.
Check IP configuration (on the
Communication Setup screen) and wait
for PanelView to connect to the network.
16388 CIP S/N is not valid Critical fault. DC incorrectly configured. Contact technical support.
16389 Out of buffers Critical fault. No buffers are available for read or write
operations.
Contact technical support.
16390 An initial write
failed
Comm Warning Write to Logic Controller on Startup was
configured and on powerup, the
PanelView could not write initial values to
a node's data table address.
or
Write to Logic Controller on Startup was
not configured and the PanelView was
unable to write a controller. Note: The
error is only displayed on the first write
attempt.
Check/define data table address in the
controller.
Check communication connections and
node configuration in the application.
16391 PV write failed Comm Warning PanelView is communicating with the
controller. The data table address does
not exist.
Check/define data table address in the
controller.
16392 PV write timeout Comm Warning PanelView is not communicating with the
logic controller.
Check connections and node
configuration in the application.
16393 PV read fail Comm Warning PanelView is communicating with the
controller. The data table address does
not exist.
Check/define data table address in the
controller.
16394 PV read timeout Comm Warning PanelView is not communicating with the
controller.
Check/define data table address in the
controller.
16397 CN object received
a reset request
Comm Warning An Ethernet object received a reset
request from a device on the network.
The PanelView does not support network
resets.
16398 The Connection
Originator is
indicating it is in
Program Mode
Comm Warning The logic controller is offline (in Program
Mode). The COMM LED on the
Configuration Mode menu is off.
Place the logic controller in run mode to
resume communication.
16399 A fatal CPU fault
occurred
Critical Fault A fatal CPU fault occurred. Contact technical support.
16401 The RAM check
failed
Critical Fault RAM verification failed at startup. Contact technical support.
