SLC 5/03, SLC 5/04, and SLC 5/05 Modular Processors 11
Publication 1747-IN009E-MU-P - April 2007
Troubleshooting Your SLC Processor
Before troubleshooting your SLC 500 system, please obtain an SLC 500 Modular
Hardware Style User Manual, publication 1747-UM011. Refer to the chapter on
troubleshooting.
In addition to the SLC 500 Modular Hardware Style User Manual, publication
1747-UM011, the SLC 500 Instruction Set Reference Manual, publication
1747-RM001, contains explanations and examples for the entire instruction set as
well as for all status words and bits. It also contains explanations for all possible
fault codes found in status word S:6.
Specifications
SLC 5/03, SLC 5/04, and SLC 5/05 Processors
Attribute SLC 5/03 SLC 5/04 SLC 5/05
L531 L532 L533 L541 L542 L543 L551 L552 L553
Memory (words) 8 K 16 K 32 K 16 K 32 K 64 K 16 K 32 K 64 K
I/O capacity,
max
4096 discrete inputs/4096 discrete outputs
Local system,
max
3 chassis / 30 slots
Programming
instructions
107
Typical scan
time
(1)
(1)
The scan times are typical for a 1 K ladder logic program consisting of simple ladder logic and communication servicing.
Actual scan times depend on your program size, instructions used, and the communication protocol.
1 ms/K 0.9 ms/K
Bit execution
(XIC)
0.44 µs 0.37 µs
Programming
software
SLC 5/03s and SLC 5/04s: RSLogix 500,
SLC 5/05s: RSLogix 500
