052793 - 03/2013
SECTION 4
PARTS
Page 4-51
Hydraulic Schematic
Parts List
ITEM PART # DESCRIPTION QTY
1 064818 LH JOYSTICK 1
2 064817 RH JOYSTICK 1
3 048661 FWD/REV. STEERING CYLINDER 2
4 048660 LEFT/RIGHT STEERING CYLINDER 1
5 046735 STEERING MANIFOLD 1
6 046738 HYDRAULIC GEAR PUMP 1
7 034012 SUCTION STRAINER 1
8 049978 RETURN LINE FILTER 1
9 046241 FILTER GAUGE 1
10 FI0350 FILLER BREATHER WITH DIP STICK 1
11 056932 SIGHT LEVEL INDICATOR 1
12 045948 MAGNETIC TANK PLUG 1
13 052930 AIR/OIL COOLER 1
14 057956 MSP455 FITTING KIT 1
15 057955 MSP455 HOSE KIT 1
To Next Page
