Alliance Laundry Systems HTT30N - Page 49

Installation
Part No. 70458301ENR7
©
Copyright, Alliance Laundry Systems LLC - DO NOT COPY or TRANSMIT 49
Gas
Type
Gas
Family
Gas
Group
Gas
Designation
Supply
Pressure
in. wc
(mbar, kPa)
Manifold
Pressure
in. wc
(mbar, kPa)
Capacity
Model
Orifice
Diameter
in. (mm)
Orifice
Part No. Quantity
55 0.1695
(4.3)
M402988 1
25 0.0820
(2.1)
M401027 1
30 0.0866
(2.2)
70070906 1
T30 0.0866
(2.2)
70070906 2
35 0.0980
(2.5)
M406361 1
T45 0.0935
(2.4)
M403017 2
G30 11.25/12
(28/30, 2.8/3.0)
Un-
regulated
55 0.1200
(3.0)
M401017 1
25 0.0820
(2.1)
M401027 1
30 0.0866
(2.2)
70070906 1
T30 0.0866
(2.2)
70070906 2
35 0.0980
(2.5)
M406361 1
T45 0.0935
(2.4)
M403017 2
LP Third I
3B/P
G30 14.9/20
(37/50, 3.7/5.0)
12
(30, 3.0)
55 0.1200
(3.0)
M401017 1
