Diagnostic
53
F8138801
Abbreviations for the Inputs and Outputs are defined
in the following table:
Outputs Outputs
AX1 Auxiliary Fill or Internal Supply 5 RFB Reuse Fill B
AX2 Unused RUN VF Motor Drive Forward
AX3 Recirculation or Reuse Drain A RV Reverse Motor Contactor
AX4 External Signal (Optional Audio) S1 Internal Supply 1
AX5 Reuse Wash Drain S2 Internal Supply 2
CF Cold Fill S3 Internal Supply 3
CS Cold Spray S4 Internal Supply 4
DN Drain SP1 Extract Motor Contactor
DR Door Unlock SPD1 VF Motor Drive Speed Select #1
ES1 External Supply 1 SPD2 VF Motor Drive Speed Select #2
ES2 External Supply 2 SPD3 VF Motor Drive Speed Select #3
ES3 External Supply 3
ES4 External Supply 4 Inputs
ES5 External Supply 5 BAL VF Drive Balance
ES6 External Supply 6 DFLT Drive Fault
ES7 External Supply 7 DL Door Lock
ES8 External Supply 8 DR Door
FW Forward Motor Contactor FSW Frame Balance Switch
HF Hot Fill OSW Optional Switch (UW150 Joggle)
HS Hot Spray PAUS External Dispenser Pause A and/or B
HT Heater PSW Low Level Pressure Switch
RDB Reuse Drain B RS Rotation Sensor (Non-Zero RPM)
REV VF Motor Drive Reverse TS Thermostat (Temp Satisfied)
RFA Reuse Fill A WL Water Level (Level Satisfied)
Table 5
