VLAN
98
The window shown in Figure 80 is displayed.
Figure 80 Network Connections Window
There are now two Local Area Connections options; one for the
network adapter and the other for the VLAN connection.
12. Right-click Local Area Connection then select Properties.
The window shown in Figure 81 is displayed.
Figure 81 Local Area Connection Properties Window
You will notice that the properties for the Local Area Connection has
only one Allied Telesyn Multi-Vlan Support Protocol. The other
protocols are disabled. The disabled protocols are options for the
Local Area Connection 2.
