Appendix A: Techn
ical Specif
ications
32
Agency Certifications
RFI Emissions
FCC Part 15 Class B, EN55022 Class B,
CISPR 22 Class B, C-TICK
Immunity
EN55024
Electrical Safety
UL 60950-1 (
C
UL
US
), EN60950 (TUV),
CE
Laser Safety
EN60825
41
43
