Allied Telesis AT-MC103SC/FSx User Manual

Appendix A: Technical Specifications
34
Fiber Optic Port Specifications
Table 9. Fiber Optic Transmitter
Model
Fiber
Type
1
1. MMF = Multimode Fiber / SMF = Single-mode Fiber
Fiber
Optic
Diameter
(microns)
Optical
Wavelength
Launch Power (dBm)
2
2. The launch power is measured at one meter from the transmitter.
Min. Avg. Max.
AT-MC101XL MMF 50/125
or
62.5/125
1310 nm -22.5 -20.3 -14.0
AT-MC102XL MMF 1310 nm -19.0 -16.8 -14.0
AT-MC103XL SMF 9/125 1310 nm -15.0 -11.5 -8.0
AT-MC103LH SMF 9/125 1310 nm -5.0 -3.0 0.0
AT-MC104XL SMF 9/125 1310 nm -3.0 0 +3.0
AT-MC104LH
3
3. This cable must be non-dispersion-shifted, dispersion-shifted, or non zero-dis-
persion-shifted single-mode fiber optic cable.
SMF 9/125 1550 nm -3.0 -0.5 +2.0
Table 10. Fiber Optic Receiver
Model
Fiber
Type
1
1. MMF = Multimode Fiber / SMF = Single-mode Fiber
Fiber
Optic
Diameter
(microns)
Optical
Wavelength
Receive Power (dBm)
Min. Typical Saturation
AT-MC101XL MMF 50/125
or
62.5/125
1310 nm -31.8 -34.5 -14.0
AT-MC102XL MMF 1310 nm -31.8 -34.5 -14.0
AT-MC103XL SMF 9/125 1310 nm -31.0 -31.0 -8.0
AT-MC103LH SMF 9/125 1310 nm -34.0 -36.0 -1.5
AT-MC104XL SMF 9/125 1310 nm -34.0 -36.0 -3.0
AT-MC104LH SMF 9/125 1550 nm -36.0 -36.0 -3.0
