AT-MC10x Series Media Converters Installation Guide
3
Figure 4 displays an AT-MC103LH Media Converter.
Figure 4. AT-MC103LH Model - Front Panel
Figure 5 displays an AT-MC104XL Media Converter.
Figure 5. AT-MC104XL Model - Front Panel
Figure 6 displays an AT-MC104LH Media Converter.
Figure 6. AT-MC104LH Model - Front Panel
746
LINK TST
M/L
ON
4
100Base-FX
LINK
ACT A/N OFF
A/N ON
100Base-TX
FDX
LINK
ACT M/L ON
PWR
TX RX
CLASS 1
LASER PRODUCT
AT-MC103LH
SINGLE MODE FIBER FAST ETHERNET MEDIA CONVERTER
LONG HAUL
749
LINK TST
M/L
ON
4
100Base-FX 100Base-FX
LINK
ACT
LINK
ACT M/L ON
PWR
TX RX
TX RX
CLASS 1
LASER PRODUCT
SINGLE MODE MULTI MODE
AT-MC104XL
SINGLE MODE /MULTI MODE FIBER FAST ETHERNET MEDIA CONVERTER
748
LINK TST
M/L
ON
4
100Base-FX 100Base-FX
LINK
ACT
LINK
ACT M/L ON
PWR
TX RX
TX RX
CLASS 1
LASER PRODUCT
AT-MC104LH
SINGLE MODE /MULTI MODE FIBER FAST ETHERNET MEDIA CONVERTER
LONG HAUL
SINGLE MODE MULTI MODE
