x510 Series Installation Guide for Stand-alone Switches
17
 Supports single-port BiDi 1000Base-LX SFP transceivers
 Supports 1000Base-ZX SFP transceivers
 Supports 10/100/1000Base-T twisted pair transceivers
Note
SFP transceivers must be purchased separately. For a list of
supported transceivers, contact your Allied Telesis distributor or
reseller.
SFP+ Slots Here are the basic features of the four SFP+ slots on the switches:
 Supports 10Gbps, 10GBase-SR/LR fiber optic transceivers
 Supports 10Gbps AT-SP10TW direct connect twinax cables with
SFP+ transceiver-style connectors
 Supports 1000Base-SX/LX SFP transceivers
 Supports single-port BiDi 1000Base-LX SFP transceivers
 Supports 1000Base-ZX SFP transceivers
Note
The SFP+ slots do not support 100Mbps 100Base-FX transceivers.
Note
SFP and SFP+ transceivers must be purchased separately. For a
list of supported transceivers, contact your Allied Telesis distributor
or reseller.
Note
SFP+ slots 27 and 28 on the 28-port switches and slots 51 and 52
on the 52-port switches are initially configured as stacking slots for
the VCStack feature. If you intend to use the switch as a stand-alone
unit, you must disable the VCStack feature before you can use the
slots with standard SFP or SFP+ transceivers. The configuration
instructions are provided later in this guide, in “Configuring the
Switch for Stand-alone Operations” on page 74.
Stacking Slots Two of the SFP+ slots can be used to create a VCStack of up to four
switches. The slots support these stacking transceivers when the switch is
in the stacking mode:
 AT-StackXS/1.0 Twisted Pair Transceiver - 1 meter
 AT-StackOP/0.3 Fiber Optic Transceiver - 300 meters
 AT-StackOP/9.0 Fiber Optic Transceiver - 9 kilometers
