Joint Cementing Procedure
All cementing of joints should be done according to the
specications outlined in ASTM D 2855.
1. Measure and cut vent pipe to desired length.
2. Debur and chamfer end of pipe, removing any ridges
or rough edges. If end is not chamfered, edge of pipe
may remove cement from tting socket and result in a
leaking joint.
3. Clean and dry surfaces to be joined.
4. Test t joint and mark depth of tting on outside of pipe.
5. Uniformly apply a liberal coat of PVC primer for PVC
or use a clean dry cloth for ABS to clean inside socket
surface of tting and male end of pipe to depth of tting
socket.
NOTE: Time is critical at this stage. Do not allow primer
to dry before applying cement.
NOTE: A sheet metal screw may be used to secure the
intake pipe to the connector, if desired. Use a drill or self
tapping screw to make a pilot hole.
DANGER OF EXPLOSION!
Fumes from PVC glue may ignite during system check.
Allow fumes to dissipate for at least 5 minutes before
placing unit into operation.
DANGER
Table 3
OUTDOOR TERMINATION KITS USAGE
A96UH2E
95G1UHE
VENT
PIPE
DIA.
(in.)
STANDARD CONCENTRIC
Outdoor
Exhaust
Accelerator
(Dia. X
Length)
Outdoor
Exhaust
Accelerator
(Dia. X
Length)
Flush
Mount
Kit
1-1/2"
Concentric
Kit
2"
Concentric
Kit
3"
Concentric
Kit
1-1/2" x12" 2" x12" 51W11** 71M80
OR
+44W92++
69M29
OR
+44W92++
60L46
OR
44W93+
030
045
2 YES YES YES
2-1/2" YES YES YES
3 YES YES YES
70 2 YES YES YES
2-1/2" YES YES YES
3 YES YES YES
90 2 YES YES YES YES
2-1/2" YES YES YES YES
3 YES YES YES YES
110 2 YES YES YES YES
2-1/2" YES YES YES YES
3 YES YES YES YES
135 3 YES YES YES
* Requires eld provided end installed 1-1/2” exhaust accelerator.
** kit 51W11 is provided with e 1-1/2” eccelerator which must be used for all 45,000 and 70,000 furnace installations.
+Termination kits 44W92, 44W93, 30g28 & 81J20 approved for use in Canadian installations to meet CSAB149.
++The 44W92 Concentric kit is provided with a 1-1/2” accelerator which must be installed on the exhaust oulet when
this kit is used with the 45,000 and 70,000 furnaces.
