507276-03Page 52 of 59 Issue 1621
Blower Data
NOTES: All air is measured external to unit without lter (lter not furnished - eld provided)
Blower Data A95UH1E & 95G1UHE
A95UH1E & 95G1UHE 030* B08 PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1025 122 935 97 855 76 820 76 765 69
0.10 985 129 910 104 820 82 775 72 700 63
0.20 955 139 875 114 770 87 640 62 575 52
0.30 915 145 830 120 730 96 575 67 375 40
0.40 875 155 790 130 680 101 530 74 330 47
0.50 830 161 750 136 635 110 470 79 260 51
0.60 800 172 700 146 580 115 420 82 210 47
0.70 765 181 650 150 550 124 385 90 180 51
0.80 715 187 615 159 500 127 325 94 135 52
