11.0GENERALGUIDELINES
11.1WELDINGONVEHICLE
Observethefollowingprecautionswhenweldingonthevehicle:
•DisconnectthewiringharnessesfromtheTCM.
•DisconnecttheTCMpowerandgroundcircuitsfromthebattery,and
anyelectroniccontrolgroundwiresconnectedtotheframeorchassis.
•Donotconnectweldingcablestoelectroniccontrolcomponents.
•Donotweldonelectroniccontrolcomponents.
•Coverelectroniccontrolcomponentsandwiringtoprotectthemfrom
hotsparks,heat,etc.
11.2PAINTINGONVEHICLE
11.2.1ElectrostaticPainting.Ifthevehiclechassisorbodyispaintedusing
anelectrostaticpaintingprocess,electricalvoltagemustnotbedischarged
throughtheTCM.Topreventthispossibility,Allisonrecommendsinstallingthe
TCMaftertheelectrostaticpaintprocessiscomplete.IftheTCMisinstalled
priortoelectrostaticpainting,makesure:
•theTCMisnotpainted.
•theelementsbeingpaintedareproperlyandcontinuouslygrounded
duringtheentirepaintingprocess.
NOTE:AllisonTransmissionisnotresponsibleforTCMdamage
resultingfromimpropergroundingduringelectrostaticpaintingof
thevehicle.
Duringelectrostaticpainting,thepaintdropletsreceiveanelectrostaticcharge
attractingthemtothegroundedsurfaces.Voltagesatthesprayguncan
exceedseveralthousandvolts.Thechargewhichbuildsuponanimproperly
groundedchassisorbodycanbedischargedthroughtheTCM,resultingin
damagetotheTCM.
152

Allison Transmission 3200 SP Specifications

General

Enclosure Rating	IP67
Input Voltage	12/24 VDC
Operating Temperature Range	-40°C to +85°C
Communication Protocol	SAE J1939
Memory	Flash and EEPROM
Diagnostic Capabilities	fault code logging
Dimensions	Varies by model
Weight	Varies by model
I/O	Digital and Analog Inputs/Outputs
Type	Transmission Electronic Control Unit (TECU)
