GenerationcontrolsshiftselectortochecktheOLS.Thismethodismore
accuratethanthedipstickmethod.
Usethedipstickmethodifanyofthefollowingsituationsexist:
•Iftransmissionuidtemperatureisbelowthetemperaturetocheckit
electronically,conductaCOLDCHECKtodeterminewhetherthereis
enoughuidtostartandmovethevehicle.
•IfthevehicledoesnothaveanAllison5thGenerationshiftselector
ortheOEMhasnotintegratedtheelectronicmessagesregardingoil
levelintotheirselector.
•IftheOLSorvehiclewiringisdefective,ortheOLSwasnotauto
detected,preventingelectronicaccesstouidlevel.
5.8.1FLUIDCHECKUSINGDIPSTICK.
Therearetwotemperaturebandsmarkedonthedipsticktoallowfor
transmissionuidexpansionwhenthetemperatureincreases.Thelower
band,referredtoasCOLDCHECK,isusedwhenthetransmissionuidis
belowoperatingtemperature.Theupperband,referredtoasHOTCHECK,
isusedwhenthetransmissionuidisatnormaloperatingtemperature.
TheOEMmayrefertotheseasCOLDFULL/COLDADD(COLDCHECK)
andHOTFULL/HOTADD(HOTCHECK).RefertoFigure5–1forfurther
informationondipstickmarkings.
NOTE:Forthelocationofthelltubeanddipstick,refertoFigure2–1
andFigure2–2fornon-PTOapplicationsandFigure2–3,Figure2–4,
andFigure2–5forPTOapplications.For4700/4800Models,referto
Figure2–6forthelocationofthelltubeanddipstick.
84

Allison Transmission 3200 SP Specifications

General

Enclosure Rating	IP67
Input Voltage	12/24 VDC
Operating Temperature Range	-40°C to +85°C
Communication Protocol	SAE J1939
Memory	Flash and EEPROM
Diagnostic Capabilities	fault code logging
Dimensions	Varies by model
Weight	Varies by model
I/O	Digital and Analog Inputs/Outputs
Type	Transmission Electronic Control Unit (TECU)
