8.0CUSTOMIZINGCONTROLSAND
TCMPROGRAMMING
8.1VEHICLEANDTRANSMISSIONSIGNALINTERFACE
OVERVIEW
Thissectiondescribesthevehicleinterfaceconnectionstothetransmission
controlsandtransmissionsignals.Thevehicleinterfacesdiscussedinthis
sectionmaybeprovidedthroughaSAEJ1939vehiclecommunications
interfaceandinclude:
•CHECKTRANSindicator
•WrenchIcon.UsedforPrognosticsfeaturesforneededscheduled
transmissionmaintenance
•RANGEINHIBITEDorRANGEINHIBITindicator
•NeutralStart
•Speedometersignal
•ReverseWarning
•Anti-LockBrakeSystem(ABS)status
•ServiceBrakestatus
•RetarderModulationsignals(ifequipped)
•EngineWaterTemperaturesignal
•RangeRequestsignals
•OthermiscellaneousTransmissionInput/Output(I/O)signalsthat
controlAuxiliaryVehiclefunctionsbyusingeitherdiscreteelectrical
signals,SAEJ1939messages,oracombinationofboth
8.2INPUTANDOUTPUTFUNCTIONSOVERVIEW
InputandOutput(I/O)functionsarebuiltintoeachtransmissioncontrol
systemtoallowadditionalfunctionalcontrolsofspecializedtransmissions
and/orauxiliaryvehicleoperationsthataretailoredfortheexpectedvocation
ofthevehicle.
137

Allison Transmission 3500 Specifications

General

Retarder	Optional
Protection Rating	IP67
Gears	6-speed
Type	Automatic
Input Voltage	12V or 24V
Communication Protocol	J1939
Operating Temperature Range	-40°C to +85°C
