9.0EXTERNALWIREHARNESSES,
VEHICLEINTERFACEMODULE,AND
RETARDERCONTROLS
9.1WIREHARNESSES
NOTE:Theexternalharnessconnectingtransmissioncontrolsis
partofthevehiclechassisharnessandtypicallywillnothavean
AllisonTransmissionpartnumber.Theharnesspartsareusually
onlyavailablethroughthevehiclemanufacturerandtheirvendors.
CheckwiththeOEMordealerrsttodeterminetheirwireharness
servicepartsavailability.AnyAllisondistributorordealercanassist
withdeterminingserviceabilityoftheexternalharnessaswell.The
internaltransmissionharnessinsidethetransmissionisanAllison
partandonlyavailablefromanAllisondistributorordealer.
Thetransmissioncontrolsrequiretheuseofwiringharnessestoconnectthe
varioussystemcomponents,including:
TransmissionControlModule(TCM)
Mainconnectoronthetransmission
Enginespeedsensor
Turbineshaftspeedsensor(4000Series)
Outputshaftspeedsensor
Serialcommunicationdatalink
Shiftselector
Diagnosticconnector
Retardercontrols(ifequipped)
Vehicleinterfacewiring
ThrottlePositionSensor(TPS)(onlywithmechanicallycontrolled
engines)
OptionalVehicleInterfaceModule(VIM)
144
