withinadenedoperatingperiodresultsinilluminationoftheCHECKTRANS
light,indicatingtheincreasedprobabilitythattheserviceconditionwilldevelop
intoamoreseriouscondition.Referto6.2.1CHECKTRANSLIGHT.
5.9.1PROGNOSTICSPREREQUISITES.Thefollowingrequirementsmust
bemettousethePrognosticsfeaturesandfunctions:
Vehicleharnesshasawireforthelterlifeindicatorswitch(wire118).
TheOEMhasorderedyourcalibrationfromAllisonTransmissionwith
Prognosticsenabled.
NOTE:ItisimportanttonotethatifPrognosticsisdisabled,itisnot
availableinthecalibration.ThisisdifferentthantheOEMordering
acalibrationwithPrognosticsoff.DefaultingPrognosticsoffmeans
itcouldbeenabledinthefuturewithoutrecalibratingtoadifferent
calibration,providedtheotherconditionsaremettousePrognostics.
UsingaTES295
®
,TES668
TM
orTES389
®
transmissionuid
UsingAllisonTransmissionHighCapacityMainandLubeFilters
NOTE:AllisonTransmissionmayapprovesomeOEMselectorsfor
Prognostics,providedtheTRANSSERVICEindicatorormessage
displayisintegratedbytheOEM.Atthetimeofthispublicationthere
arenocapableOEMselectorsforPrognostics.
5.9.2PROGNOSTICSFEATURESAVAILABILITY .Thevehiclemanufacturer
specieswhethertheywantAllisonPrognosticsFeaturePackagetobemade
availableinthecalibrationandinwhatconguration;forexample,defaulted
onoroff.TheOM,FM,andTMaretheindividualfunctionsincludedinthe
AllisonPrognosticsFeaturePackage.Theseindividualfunctionscannotbe
turnedonoroffseparatelywithintheAllisonPrognosticsFeaturePackage.
Thetransmissioncalibrationcanbemadeforthevehiclemanufacturer(orthe
customer)sothePrognosticsFeatureisinoneofthefollowingstates:
AvailableandthePrognosticsFeaturesaredefaultedonandtherefore
monitoringOM,FM,andTMpresently.
Availableandthefunctionisdefaultedoffandthereforeavailablebut
notmonitoringOM,FM,andTMpresently.
DisabledandthereforenotavailablewithinthisTransmissionControl
Module(TCM)calibration.
MethodstoturnthePrognosticsPackageFeaturesonoroff(providedall
otherrequirementsaremet),includethefollowing:
94
