Allison Transmission 3500 User Manual

NOTE:Thetransmissionretarderisconguredaseitheralow,
medium,orhighcapacityretarderbyTCMcalibration.Allison
TransmissionrequireswrittenvehicleOEMapprovalbeforeaservice
outletincreasestheretardercapacityatacustomer'srequest.
Existingvehicledrivelines,differentials,axles,andthecoolingsystem
mustbedesignedfortheadditionalretardertorquegeneratedifa
highercapacityretardercalibrationisinstalled.Thecosttomodify
retardercapacityistheresponsibilityofthecustomer.
TheamountofRetarderModulationRequest(RMR)iscontrolledbythe
operatoranddependsonthetypeofretardercontrolusedinthevehicle.
Varioushand,footandautomaticcontroltechniquesareused.Referto
Table4–7.BeginningwithAllison5thGenerationControls,theTCMalso
activatesorlimitsretarderoperationinresponsetotorquespeedcontrolor
electronicretardercontrolmessagesreceivedonthevehicle’sSAEJ1939
Datalink.ContactyourOEMtounderstandhowtheretardercontrolshave
beenintegratedintoyourvehicle.
ThepresenceofaretardermustbeautodetectedbeginningwithAllison5th
GenerationControls.
NOTE:Theretarderenableswitchisusedtoturntheretarderofffor
slipperyroadconditions.
73

Allison Transmission 3500 Specifications

General

Retarder	Optional
Protection Rating	IP67
Gears	6-speed
Type	Automatic
Input Voltage	12V or 24V
Communication Protocol	J1939
Operating Temperature Range	-40°C to +85°C
