Page 9
The connector is shared with the serial port (See Figure 2 item 8). The pinout is shown in Table 4 below.
Pin Signal Direction
2 (do not connect) RX Input
3 (do not connect) TX Output
5 (do not connect) GND --
9 Relay COM --
6 Relay NC --
1 Relay NO --
Table 4: Door Relay Pinout
To configure the door relay/paging amplifier:
1. Open your browser and enter the URL of
http://192.168.2.254:8080 or current IP address.
2. In the Phone System group select Paging.
3. Click Modify in the Page Amplifier area.
4. Select DB9 is connected to a Door Entry System to enable door relay or Paging Amplifier to enable
amplifier.
5. Click Update.
To activate the door relay:
1. From any handset connected to the system dial extension 403.
