6x Installation Guide
300 Main Street • East Rochester, NY 14445 • Toll Free 1-866-ALLWORX • 585-421-3850 • www.allworx.com
© 2007 Allworx Corp. All rights reserved. Allworx is a registered trademark of Allworx Corp. All other names may be trademarks or registered
trademarks of their respective owners.
Revised: December 27, 2007
Page 8
substitute the 256MB flash card provided with a larger capacity compact flash card prior to initial configuration.
The unit is compatible with SanDisk Ultra
®
II CompactFlash
®
cards that support DMA capability.
To install a new Compact Flash card:
1. With the power off, insert the new CompactFlash card into the compact flash slot on the server (See Figure
1 item 7). Make sure that the CompactFlash card is inserted securely to prevent spurious interrupt
messages that can occur when the CompactFlash card is just touching the connectors.
2. Power on the server (note it will boot into Safe Mode).
3. Set up the PC’s network interface to obtain an IP address automatically (using DHCP).
4. You may need to release and renew the PC’s IP address to get an address from the server.
5. Verify that the PC has an IP address on the 192.168.2.xxx network.
6. Open your browser and enter the URL of
http://192.168.2.254:8080 or current IP address.
7. In Safe Mode select Format under Disk Operations.
8. Click OK to format.
9. Enter the word yes format when prompted.
10. Once the formatting is complete, perform a software update.
11. Once the software update is complete reboot normal mode.
12. Your new Compact Flash card should now be ready to use.
To remove a Compact Flash card:
1. Grasp the center of the card with thumb and index finger.
2. Tug forward gently.
6.5 Door Relay/Paging Amplifier
Unit comes with a single set of C-form relay contacts for connecting to external devices such as remote door
releases and amplifiers. The contacts are rated 30 VDC @ 1A.
Warning: Do not exceed the contact rating.
