9 Data Network
The Local Area Network (LAN) and Wide Area Network (WAN) data network ports are 10BaseT/100BaseTX
auto-sensing and auto-MDI/MDIX ports.
The Allworx 6x is a sophisticated network appliance that must be properly configured before being connected
to the LAN and WAN.
Note: Do not plug any network or ISP service into the server without first properly configuring the server.
Failure to heed this warning may result in a disruption of network connectivity with other equipment on
the network.
After the unit is properly configured, the LAN and WAN network infrastructure cables can be plugged in.
Standard RJ-45 category 5 network cables must be used.
The LED’s on the LAN and WAN ports are defined in
Table 7.
LED Identification State Description
Off No link: the network is not connected
On Link: the network is successfully connected
Green
Blinking Activity: data is being transmitted or received
Table 7: Network Port LED Definitions
