PAGE 104 ALMAC s.r.l.
6.2.15 Checking the tracks for wear
Check the wear and condition of the tracks, replacing them when the tread is
equal to or less than 10 mm.
The tracks must be changed even before they reach this limit if they are cuts or
tears are noted.
Tracks must only be replaced by specialized, properly trained personnel.
Follow the “track replacement” procedure illustrated on the following pages.
6.2.16 Replacing the tracks
WARNING: it is forbidden to open the reducer for any operation not provided for
by scheduled maintenance. The manufacturer shall not be held responsible for
any operations not included in scheduled maintenance that have caused damage
to property and/or harmed people.
WARNING: USE PERSONAL PROTECTIVE DEVICES
Replacing the track
The track must be replaced when 10 mm of tread is left or even earlier if there
are any cuts. Proceed as follows:
1. Do not lift the machine from the ground excessively (15-20 cm are
enough).
WARNING: make sure that the machine is stable.
2. Thoroughly clean all the parts of the undercarriage.
3. Remove the side closure of the longeron (1).
