PAGE 73 ALMAC s.r.l.
5 Emergency procedures
5.1 Reception problems with remote control
If the radio control console does not work correctly, it is possible to use the
cable supplied (1) to connect it to the machine using the connector (2).
5.2 Transporting the machine in an emergency
To move or transport the machine using external equipment, refer to paragraph
2.5
5.3 Emergency movements from hydraulic block
Warning: this operation must be performed only by qualified technicians trained
by Almac S.r.l.
In the event that there is a malfunction of the control unit but it is possible to
switch on the electric motor, the movements of the machine can then be
performed directly from the hydraulic block.
To perform the movements it is necessary: to release (by turning anti-clockwise)
the safety valve 3 and screw (by turning clockwise) the valves 1 and 2 (provided
with a lead seal).
