PAGE 57 ALMAC s.r.l.
4.2.2 Travel controls
The controls used for the movement of the platform are represented by 2
joysticks (9-10) located on the control panel. (see photo below).
Each lever controls the respective track (right lever→right track, left lever→left
track).
Move the lever forwards to drive the platform forwards. Move the lever
backwards to drive in reverse.
You can work with one track at a time, depending on the movement required at
that particular moment.
The platform is fitted with a tracked chassis with dual speed gear motors
equipped with a negative brake, therefore the machine will remain blocked
whenever the forward or backward movement is interrupted.
To turn the control stations, move the levers as indicated in the following
illustrations.
