PAGE 60 ALMAC s.r.l.
4.2.2.2 Easy-Drive System (ED-S)
Moving the selector (6) on the push-button panel to the "ED-S" position activates
a special function that allows you to control the rotation of the control stations,
especially when operating on cultivated or grassy terrain, so that the tracks do
not rip the cultivation during the manoeuvre.
In fact, the activated function controls, in addition to the selected track, also
the movement of the other track but at a lower speed.
This allows for controlled steering.
When this function is selected, counter-rotation is not enabled.
4.2.2.3 Direct-Control System (DC-S)
By moving the selector on the push-button panel to the "DC-S" position, you can
use only the right Joystick (10) to move in the driving direction, maintaining a
straight trajectory without having to correct the direction with the other
joystick.
