PAGE 66 ALMAC s.r.l.
4.3 Positioning of the load on the machine
The machine has been designed and built for loading and moving various
materials and/or equipment.
The loading platform has dimensions of 1.11 meters x 2.40 meters, and has a
maximum capacity of 6000 kg – 13227.7 lbs.
ATTENTION: The load must always be fixed to the machine frame by means of
safety straps, to be fixed to the holes present along the entire perimeter of the
frame.
ATTENTION: When levelling the vehicle, make sure that the load is not in danger
of collision with the surrounding environment.
Using the 8 tubular elements in the structure it is possible to use the subframes
(not supplied as standard) to support and/or block the loaded material.
