SPC 20 OPERATOR’S MANUAL
G4 SPECIFICATIONS
A
B
C
D
E
CYCLONE BLOWER
Type: Centrifugal Fan Air Speed: 7350 - 9050 fpm
Diameter: 13.5” (34.29 cm) Speed Control: Variable Pitch Sheave
ELECTRICAL
Charging System: 55A alternator Battery: 12V negative ground
DIMENSIONS
A: Wheel Base: 6’-4”
B: Base Machine: 10’-2”
C: Machine w/ head: 17’ 6”
Width: 7' (Not Shown)
(Options Can Modify Width)
D: Height: 7’-6”
E: Ground Clearance: 11”
Machine Gross Weight: 5500lbs
(Options will modify weight)
Standard Head Weight: 1800lbs
Row Crop Head Weight: 2600lbs
Corn Head Weight: 2400lbs
