Dockings
General
SPLIT can be connected in several different ways, some of
which are shown on the following pages.
Installation requirements
L12 SPLITL8 SPLIT
0.25 MPa (2.5 Bar)Max pressure, climate system
55/45 °CHighest recommended supply/return temperature at dimensioned outdoor
temperature
+65 °CMax temperature in HM 8-12 SPLIT
+58 °CMax flow line temperature with compressor
+7 °C/+18 °CMin supply temperature cooling, HM 8-12 SPLIT
+25 °CMax supply temp. cooling
80 l50 lMin volume, climate system during heating, cooling*
100 l80 lMin volume, climate system during under floor cooling*
0.57 l/s0.38 l/sMax flow, climate system
0.29 l/s0.19 l/sMin flow, climate system, 100 % circulation pump speed (defrosting flow)
0.15 l/s0.12 l/sMin flow, heating system
0.20 l/s0.16 l/sMin flow, cooling system
WWS 500 SPLITWWS 300 SPLITDocking external addition
9–27 kWOutput external addition
0.17–0.33 l/sRecommended docking flow
* Regards circulating volume.
External circulation pump must be used when the pressure drop in the system is greater than the available external pressure.
In such cases, a bypass line with non-return valve must be installed.
Overflow valve must be used if min. system flow cannot be guaranteed.
Symbol key
MeaningSymbol
Venting valve
Shut-off valve
Non-return valve
Control valve
Safety valve
Temperature sensor
Expansion vessel
Pressure gauge
