ALPHA LITE ALPHA 3000 - Master Setup

Product name.
19
ALPHA 3000
ex
Master
#Last
#1
#2
#3
- Remove 'DMX in' cable.
- Set ‘Master Enable’
- Set the same
channel mode.
- Operation After setting.
- Connecting
'DMX in & out' cable.
- Set ‘Master Disable’
- Set the same
channel mode.
- No operation
after setting.
Extra Function
– Sleep Mode / Master / RDM / Dimming Speed
Master Setup
• The master slave function allows to synchronize and control all connected lighting
fixtures through the DMX signal without a console connection.
• If a problem occurs in the console or communication line, it is possible to control
the brightness and CCT and color with only the lighting fixture.
• Main screen ▶ Setting ▶ Touch MASTER SETUP, the function turns on. (2 Touch)
• Functions available with one setting of the first lighting fixture.
〔 Main Screen 〕 〔 Fixture ID Screen 〕
Touch!
Touch!
DMX cable connect
