Product name.
7
ALPHA 3000
Technical Specifications
LED Chip Type
1100W 6 Color + 2 White LED engine
Estimated LED Lifetime (hours)
50,000
White Light (K)
2,000~35,000 (VCT/FCT)
Full Color Light
Full RGB + Amber + Lime + Cyan + Warm White + Cool White
(7Color Gamut with Hue and Saturation Control)
Color Rendition (%)
CRI 95~99.5 / TLCI 95~99.5
Dimming (%)
0~100 (16-bit)
Lens Diameter (mm/inch)
250 / 9.8
Beam Angle ( °)
15~55
Signal Control
5-Pin DMX In and Out
Individual Control
Smart Touch LCD Controller
Supported Protocol
DMX512 / RDM
(Optional) Supported Protocol
DMX512 Wireless / RDM Wireless
Remote Device Management
Supported
Channel Function
Dimming / CCT / Tint / RGBALC / Cross Fader / Color Macro / Strobe
Power Input Voltage
AC 100-240V / 50~60Hz
Power Consumption (W)
600
Ambient Temperature
Operation ( °C)
-20~45
Spigot Mounting (mm)
16 / 28
Tilt Angle ( °)
+ / - 90
Body Dimensions
(mm/inch) (WHD)
328 x 404 x 464 / 12.9 x 15.9 x 18.3
Full Dimensions with Manual
Yoke (mm/inch) (WHD)
432 x 605 x 464 / 17 x 23.8 x 18.3
Body Weight (kg/lbs)
12.3 / 27.1
Full Weight with Manual Yoke
(kg/lbs)
13.8 / 30.4
Protection Class
IP20
* This specification data is based on the aging state of the equipment,
and the brightness and color temperature before and after aging may be different.
