25
OPERATION
ENGINE SWITCH
OOFFFF
OONN
STARTER GRIP
CHOKE KNOB
OPEN
Turn the engine switch to the
ON position.
Pull the starter grip lightly until
you feel resistance, then pull
briskly.
Pull the starter grip as shown in
the picture at the right.
Do not allow the starter grip
to snap back against the
engine. Return it gently to
prevent damage to the starter.
Do not let the starter rope rub
against the generator body or
the rope will wear out
prematurely.
If the choke knob was pulled to
the CLOSED position to start
the engine, gradually move it to
the OPEN position as the
engine warms up.
When the engine starts, DC output will begin charging the UPS battery
string automatically and the output indicator (green) will go ON. If the
UPS battery string voltage is too low, the DC output will be turned off.
At this time, the output indicator (green) will go OFF and the overload
indicator (red) will go ON. See Forced Output, page for additional
information.
5.
6.
7.
