AlphaGen DCX3000 - Servicing: Spark Plug; Spark Plug Service

41
SERVICING YOUR GENERATOR
SEDIMENT CUP CLEANING
BREATHER HOSE
AIR CLEANER BASE
6mmBOLT
6 mm NUTS
Turn the fuel valve lever to the OFF position.
Remove the air cleaner cover, foam and paper air filter (see page ).
Disconnect the breather hose from the air cleaner base.
Remove the 6 mm bolt and two 6 mm nuts, and remove the air
cleaner base.
Open the maintenance cover.
1.
2.
3.
4.
5.
38
04/10/12 11:52:29 31ZS9700_042
