42
SERVICING YOUR GENERATOR
FILTER
SEDIMENT CUP
SEDIMENT CUP
O-RING
(replace)
Remove the sediment cup by turning it counterclockwise.
Gasoline is highly flammable and
explosive.
You can be burned or seriously
injured when handling fuel.
Reinstall the paper air filter and air cleaner cover.
Reinstall the air cleaner base, and connect the breather hose with
the air cleaner base.
Wash the sediment cup, O-ring and filter in nonflammable solvent,
and dry them thoroughly.
Stop the engine and keep heat,
sparks, and flame away.
Handle fuel only outdoors.
Wipe up spills immediately.
Reinstall the filter, new O-ring, and sediment cup.
Close and latch the maintenance cover.
6.
7.
8.
9.
10.
11.
