10-EN
Receiving a Multicast Station (HD Radio™
mode only)
Multicasting is the Ability to broadcast multiple program streams over a
single FM frequency. This increases the amount and diversity of content
choices. A maximum of eight multicast station channels can be selected
on this unit.
When multicast station is received, the program number and the SPS
indicator lights up.
1
Press or to select the desired program service.
Receiving the Multicast Station Program Service.
Program Service example:
The RBDS (Radio Broadcast Data System) is a radio information
system. The RBDS allows you to receive a variety of information such as
traffic information, station names.
The RBDS digital data includes the following:
Setting the Time to automatically Adjust
When you set to ON, the time is automatically adjusted by RBDS data.
1
Press and hold SETUP for at least 2 seconds to activate the
SETUP mode.
2
Turn the Rotary encoder to select the Tuner mode, and
then press ENTER.
Bluetooth
*1
General Display Tuner
*2
/HD Radio
*3
XM
*4
/
SIRIUS
*5
Bluetooth
*1 Displayed only when INT Mute is OFF, and the mode is set to
other than Bluetooth Audio.
*2 Not displayed when HD Radio Tuner module is connected.
*3 Only when HD Radio Tuner module is connected.
*4 Only when XM Radio is connected.
*5 Only when SIRIUS Radio is connected.
3
Turn the Rotary encoder to select Auto Clock, and then
press ENTER.
4
Turn the Rotary encoder to select ON or OFF.
5
Press and hold SETUP for at least 2 seconds to return to
normal mode.
Notes
•Pressing ESC during the procedure will return to the previous
mode.
• If no operation is performed for 60 seconds in the SETUP mode, the
setting mode is canceled.
Multicast
Radio Station
Program No. Program Service
90.3 MHz No.1 MPS: Main Program Service
90.3 MHz No.2 SPS: Sub-program Service
90.3 MHz No.3 SPS: Sub-program Service
90.3 MHz No.4 SPS: Sub-program Service
90.3 MHz No.5 SPS: Sub-program Service
90.3 MHz No.6 SPS: Sub-program Service
90.3 MHz No.7 SPS: Sub-program Service
90.3 MHz No.8 SPS: Sub-program Service
RBDS
PS Program Service Name
TP Traffic Program
TA Traffic Announcement
FUNC./SETUP
/ESC
BAND
TA
3 PTY
VIEW
Tag
Rotary encoder/ENTER/
To Next Page
