Alpine CDE-143EBT User Manual

14-EN
Audio Setup
You can flexibly customize the unit to suit your own preference and
usage. From the AUDIO SETUP menu, Audio Setting can be modified.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select AUDIO, and then press
ENTER.
AUDIO  GENERAL  DISPLAY  TUNER  iPod  BLUETOOTH
3 Turn the Rotary encoder to select the desired sound
setting menu, and then press ENTER.
FAC TO RY EQ
*1/*2
 3BAND EQ
*1/*3
 VOL LV ADJ  HPF
*1

SUBWOOFER  SUBW LPF
*1/*4
 SUBW PHASE
*4

SUBW SYS
*4
 POWER IC  MX SETTING
*1
(e.g. Select SUBWOOFER)
*1 Adjustment cannot be performed when DEFEAT is set to ON.
*2 Any changes made to either FACTORY EQ or 3BAND EQ are
reflected in the others’ settings.
*3 In step 3, three sound adjustment items (Bass, Mid and Treble)
can be selected in 3BAND EQ mode. Turn the Rotary encoder
to select the desired item, and then press ENTER to continue
to step 4.
*4 These functions are inoperable when SUBWOOFER is set to
SUBW OFF.
4 Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select SUBW ON or SUBW OFF)
5 Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
• Pressing r returns to the previous Sound menu mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, Sound menu mode is
cancelled.
10 typical equalizer settings are preset at the factory for a variety of
musical source material. USER settings are created in the 3BAND EQ
mode.
 Setting item: FACTORY EQ
Setting contents:
USER / FLAT (Initial setting) / POPS / ROCK / NEWS / JAZZ /
ELEC DANCE / HIP HOP / EASY LIS / COUNTRY / CLASSICAL
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste. The setting of Bass, Mid and Treble can
be adjusted in this mode.
 Setting item: 3BAND EQ
 Further setting items: BASS / MID / TREBLE
Setting the Bass Control
1 After selecting BASS from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired Bass
setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3 Press r to return to the previous step.
 Setting the Bass Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired bass
bandwidth.
WIDE 0.50  MEDIUM 1.00  MEDIUM 1.50  NARROW 2.00
Changes the boosted bass bandwidth to wide or narrow. A wider setting
will boost a wide range of frequencies above and below the centre
frequency. A narrower setting will boost only frequencies near the
centre frequency.
 Setting the Bass Centre Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired bass centre
frequency.
60 (Hz)  80 (Hz)  100 (Hz)  120 (Hz)
Emphasises the displayed bass frequency ranges.
 Setting the Bass Level
Turn the Rotary encoder to select the desired bass level
(-7 ~ +7)
*
.
You can emphasise or weaken the bass level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 13.
Setting the Mid Control
1 After selecting MID from the 3BAND EQ adjustment mode,
turn the Rotary encoder to select the desired setting item,
and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3 Press r to return to the previous step.
Use steps 1 to 5 to select one of the setting modes to modify.
See the applicable section below for details about the
selected setting item.
Equalizer Presets (F-EQ)
Adjusting the Parametric Equalizer Curve
(3BAND EQ)
00ALPINE.book Page 14 Friday, November 16, 2012 4:10 PM
