Alpine CDE-143EBT User Manual

15-EN
 Setting the Mid Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired Mid
bandwidth.
WIDE 0.75  MEDIUM 1.00  MEDIUM 1.25  NARROW 1.50
 Setting the Mid Centre Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired Mid centre
frequency.
500 (Hz)  1.0k (Hz)  1.5k (Hz)  2.5k (Hz)
 Setting the Mid Level
Turn the Rotary encoder to select the desired Mid level
(-7 ~ +7)
*
.
You can emphasise or weaken the Mid level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 13.
Setting the Treble Control
1 After selecting TREBLE from the 3BAND EQ adjustment
mode, turn the Rotary encoder to select the desired
Treble setting item, and then press ENTER.
WIDTH (Q)  CENTER FRQ  LEVEL
2 Turn the Rotary encoder to select the desired setting
value, and then press ENTER.
3 Press r to return to the previous step.
 Setting the Treble Bandwidth (WIDTH (Q))
Turn the Rotary encoder to select the desired treble
bandwidth.
WIDE 0.75  NARROW 1.25
 Setting the Treble Centre Frequency (CENTER FRQ)
Turn the Rotary encoder to select the desired treble
centre frequency.
7.5K (Hz)  10.0K (Hz)  12.5K (Hz)  15.0K (Hz)
 Setting the Treble Level
Turn the Rotary encoder to select the desired treble level
(-7 ~ +7)
*
.
You can emphasise or weaken the treble level.
* The adjustment can also be made by pressing AUDIO. Refer to
“Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and
Rear)/Defeat” on page 13.
The output level of each source is individually adjustable. For example, if
the TUNER level sounds lower than CD, its output can be adjusted
without affecting the other sources.
 Setting item: VOL LV ADJ
 Further setting items: TUNER / DISC
*
/ USB / iPod /
BT AUDIO / AUX
Setting contents:
-14 dB ~ +14 dB
* Only for CDE-143EBT/CDE-143EBTTH.
The High Pass Filter on this unit can be adjusted to suit your personal
taste.
 Setting item: HPF
Setting contents:
HPF OFF (Initial setting) / HPF 60 (Hz) / HPF 80 (Hz) /
HPF 120 (Hz) / HPF 160 (Hz)
All frequencies above the selected cutoff are output.
When the subwoofer is on, you can adjust the subwoofer output level
(refer to “Adjusting Subwoofer Level/Bass Level/Mid Level/Treble Level/
Balance (Between Left and Right)/Fader (Between Front and Rear)/
Defeat” on page 13).
 Setting item: SUBWOOFER
Setting contents:
SUBW OFF / SUBW ON (Initial setting)
OFF:
No subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 38).
ON:
The subwoofer signal is output from the Subwoofer RCA
Connectors (refer to “Connections” on page 38).
The Low Pass Filter on this unit can be adjusted to suit your personal
taste.
 Setting item: SUBW LPF
Setting contents:
LPF OFF (Initial setting) / LPF 60 (Hz) / LPF 80 (Hz) /
LPF 120 (Hz) / LPF 160 (Hz)
All frequencies lower than the selected cutoff are output.
The subwoofer output phase is toggled SUBWOOFER NORMAL (0°) or
SUBWOOFER REVERSE (180°). To adjust the level, turn the Rotary
encoder.
 Setting item: SUBW PHASE
Setting contents:
NORMAL (Initial setting) / REVERSE
Setting the Source Volume Level
Adjusting the High Pass Filter
Turning Subwoofer ON/OFF
Adjusting the Low Pass Filter
Setting the Subwoofer Phase
00ALPINE.book Page 15 Friday, November 16, 2012 4:10 PM
