Alpine DVA-5210 - TERMINAL VOLTAGE(7)

DVA-5210
123456
Q2003 5 2.7 5 3.3 2.6 3.3
Q8005 0.05 0.05 0.04 6.8 4.8 0.04
Q8010 0.05 0.05 0.04 6.8 4.8 0.04
12345
Q3005 PS 0 PS 0.5/9.4 0.5/9.4
Q3006 PS 0 PS 0.5/9.4 0.5/9.4
Q3009 7.1 0 7.1 0 0
Q3010 14/0 0.5/14 14 0/3.1 0
Q5004 NC 7 7 4.5 0
Q8001 0 5.0 5.0 5.0 0
Q8002 0 5.0 5.0 3.5 0
Q8017 0.05 14 14 4.8 0.04
ECB
Q2004 PS 5.0 PS
Q2007 PS 7.0 PS
Q2008 0 4.2 0.5
Q3011 0 0/3.1 4.8/0
Q4003 0.04 PS PS
Q4004 0.05 10.2/0.1 0.05/2.9
Q4005 0.04 0.07/10.2 5.8/0.05
Q4006 0.04 5.8/0.05 0.04/2.9
Q4007 0.04 10.7/0.1 0.04/2.9
Q4008 0.04 0.08/10.3 5.8/0.06
Q4009 0.04 5.8/0.06 0.04/2.9
Q4010 0.05 10.2/0.1 0.05/2.9
Q4011 0.04 0.08/10.2 5.8/0.0
Q4012 0.04 5.8/0.05 0.04/2.9
Q5001 0 5.0 0
Q5002 5 4.9 4.3
Q5003 0.05 0.06 4.5
Q5005 1.7 PS PS
Q5006 5.7 PS PS
Q5007 0 PS 0.3
Q8003 5.0 5.0 4.3
Q8004 0 0 4.6
Q8008 PS PS 0.05
Q8011 5.0 0.04 0.04
Q8012 0.13 0.04 0.13
Q8013 0.04 0.13 0
Q8014 0.04 0.13 0.65
Q8015 0.04 2.4 2.4
Q8016 12.0 14.0 12.5
Q9501 0.05/0 0.05/3.3 4.2/0
Q9701 0.05 0.04/3.3 4.2/0
Q9801 1.4 0.05 0.6
[Measuring Conditions]
1.Power Supply Voltage : DC13V
2.Measuring Meter : Digital Multi Meter
3.Measuring Point Reference : Between GND
4.Measuring Condition : TEST DISC PLAY
Normal/MUTE
Normal/MUTE
Normal/MUTE
Normal/MUTE
CD PLAY/Others
CD PLAY/Others
CD PLAY/Others
DVD PLAY/Others
Normal/Reset
Normal/Reset
DVD PLAY/Others
DVD PLAY/Others
MP3 WMA PLAY/Others
MP3 WMA PLAY/Others
- 32 -
