28-EN
Specifications
PICKUP
REMOTE CONTROL
GENERAL
CHASSIS SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION
Frequency Response CD: 5 – 20,000 Hz (± 1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.02 % (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Channel Separation 65 dB (at 1 kHz)
Horizontal resolution 500 lines or greater
Video output level 1Vp-p (75 ohms)
Video S/N ratio DVD: 60 dB
Audio S/N ratio 95 dB
Wave length DVD: 665 nm
CD: 800 nm
Laser power CLASS II
Battery Type CR2025 battery
Width 42 mm (1-5/8")
Height 90 mm (3-1/2")
Depth 11.6 mm (15/32")
Weight 30 g (1 oz) (battery excluded)
Power Requirement 14.4 V DC
(11–16 V allowable)
Operating Temperature +14°F to +140°F
(-10°C to + 60°C)
HDMI Output Format 480p
Weight 1.2kg (2 lbs. 10 oz)
Width 170 mm (6-3/4")
Height 50 mm (2")
Depth 154 mm (6-1/16")
CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM
(Bottom side of player)
