System Example
Connection of a USB Memory
• Do not leave USB memory, in a vehicle for a long time. Heat and humidity may damage the USB memory.
Connection of an iPod/iPhone
*
1
If iPod VIDEO is supported, use the iPod VIDEO extension cable.
• Do not leave a iPod/iPhone in a vehicle for a long time. Heat and humidity may damage the iPod/iPhone and you may not be able to play it again.
• To connect an iPod/iPhone, an optional connection kit KCU-461iV is required.
USB Memory (Sold separately)
USB extension cable
(Included)
USB connector
USB connector
USB extension cable (Included)
iPod VIDEO AV extension cable*
1
(Included with KCU-461iV)
Connection kit KCU-461iV
(Sold separately)
iPod/iPhone
(Sold separately)
iPod VIDEO input
connector
