System Example
Connection of an iPod/iPhone or USB memory
• Do not leave a iPod/iPhone/USB memory in a vehicle for a long time. Heat and humidity may damage the iPod/iPhone/USB memory and you may
not be able to play it again.
Connection of a Rear Monitor
Video Output Connector (AUX OUTPUT)
RCA Extension Cable (Sold Separately)
USB Memory (Sold separately)
USB extension cable (Included)
USB connector
iPod/iPhone
(Sold separately)
iPod VIDEO input connector
Connection kit KCU-461iV
(Sold separately)
or
iPod VIDEO AV extension cable
(Sold separately) (KCU-461iV)
(Yellow)
CAMERA/AUX/PRE OUT cable
To Rear Monitor Input terminal
Rear Monitor
(Sold separately)
CAMERA/AUX/PRE OUT Connector
To Next Page
