6490009ENLZ / 6790009ENLZ
►
8
◄
Al
sipercha with housing tube Alsipercha System
System limitations
:
- The maximum number of users in each system will only be
1 (one). The system's resistance capacity is based on the
weight of the person using it and the lightweight tools that may
be carried, and this weight must not exceed 100 Kg in total.
- The structure where the system is assembled must be
suffi ciently resistant.
- The maximum action radius, once the system is anchored,
is 6.5m. Do not try to widen this radius by lengthening the
retractable system to which it is tied
Precaution
- ONLY use slings supplied by Alsina.
- Do not keep weight hanging from the sling, as this may damage it.
- Protect the sling from inclement weather conditions.
- Each sling must be checked before being used. Reject it if it
has any cuts, particularly if the cuts are at the ends.
- Place the sling in its correct position of use and the load stable.
Step 4/4_Repositioning the Alsipercha
Example of onsite layout
LEGEND
Columns with a housing tube 1.- Starting the boarding of the
fl oor
2.- Direction of progress during
boarding process
Alsipercha body - 2.5 m
Working radius - 6.5 m
Distance between columns - 8.5 m
To facilitate use of the Alsipercha, we recommend prior planning of the
working area where it is going to be used.
Thanks to advanced CAD systems, we can know where to place the
Alsiperchas and how many are needed to optimize their use within the
working radius.
Info
. A set of approximately 6 Alsipercha units are suffi cient
for complete formwork of a fl oor measuring approximately
500 m
2
.
8.5 m max.
2.5 m
6.5 m
The Alsipercha allows the worker to change anchorings before
unhooking from the fi rst Alsipercha Body, so safety is maintained at all
times.
Use the hook to do this if the next
Alsipercha is positioned so that the worker
cannot reach to anchor themselves.
